- 1 Channel
- 12/24 VDC/VAC
- 10KA
| FUNCTION | Video Power Data |
| RESPONSE TIME | <1ns <25ns <1ns |
| NORMAL DISCHARGE CURRENT (in 8µs) | 5KA |
| MAXIMUM DISCHARGE CURRENT (in 8µs) | 10KA |
| RATED VOLTAGE | 5VDC 12V/24VDC/VAC 5VDC |
| LIMITED VOLTAGE | 20VDC 30V/60VDC 20VDC |
| MAX TRANSMISSION RATE (Mbps) | 10 Mbps — Mbps |
| INSERTION LOSS (dB) | <0.2dB — 0.5dB |
| CONNECTOR TYPE | BNC 2P 2P |
| DIMENSION | 90mm(l) × 64mm(w) × 23mm(h) |
| WEIGHT | 200g |
| SHEATHING MATERIAL | Shield metal Shell |
