Key FeaturesTechnical SpecificationsDownload
- 12 VDC
- 90 – 240 VAC Input
- 1 AMP Output
- 12W
OPTIONAL
- EU 2 Pin
- USA 2 Pin
| INPUT VOLTAGE | A100-240, 50/60Hz |
| RANGE VOLTAGE | AC90-264, 47/63HZ |
| OUTPUT SPECIFICATION | |
| OUTPUT POWER | 12W |
| OUTPUT VOLTAGE | 12V |
| OVER VOLTAGE PRODUCTION | 120% min |
| OVER CURRENT PRODUCTION | 120% min |
| SHORT CUT PRODUCTION | Auto Recover |
| LOAD REGULATION | 5% |
| OPERATING TEMPERATURE | 0˚C ~ 40˚C |
| STORAGE TEMPERATURE | -20˚C ~ +85˚C |
| HUMIDITY | 5% ~ 95% RH |
| WITHSTANDING VOLTAGE | AC 3000V (Min), 5mA (Max) |
| INSULATION RESISTANCE | DC500V 100M (Min) |
| MTBF | > 54,000Hrs |
| DIMENSION | 60 (L) x 54 (W) x 25 (H) mm |
