Key FeaturesTechnical SpecificationsDownload
- Back Light LCD
- 3-Axis Joystick Controller
- Controller for Pan, Tilt and Zoom
- Controls up to 255 Camera
- Proprietary Protocol
OPERATING TEMPERATURE-10ºC to 50ºC (-14ºF to 122ºF)
| INTERFACE | RS – 485 |
| DISTANCE | Maximum 1.2km on UTP cable |
| COMMUNICATION SPEED | RS485-9600bps |
| JOYSTICK | 3-axis, Pan/Tilt, Zoom, Power, Auto Pan, Preset, Group, Tour, Trace, AUX Control x 4 (Camera Power, Light Power, AUX 1-2) |
| POWER SUPPLY | 12VDC, 1A |
| POWER CONSUMPTION | Max 200mA |
| OPERATING TEMPERATURE | 0ºC ~ +40ºC |
| DIMENSION | 302.4mm (w) x 47.7mm (h) x 167.8mm (d) |
| WEIGHT | Approx 0.8kg |
