Key FeaturesTechnical SpecificationsDownload
- 1 Channel Input
- 10/100Mbps
- Maximum Distance : 5000m
- 12 VDC
| Category Description | |
| POWER | Available Voltage Range 12VDC Power Consumption <4.5W |
| TRANSMISSION | Transmission Total Transmission Rate Transmission Distance Transmission Rate |
| RATE | Distance (Maximum) (Download maximum) (Uplink Maximum) 150m 148Mbps 74Mbps 74Mbps 300m 90Mbps 54Mbps 36Mbps 600m 43Mbps 23Mbps 20Mbps 900m 30Mbps 15Mbps 15Mbps 1200m 15Mbps 9Mbps 6Mbps 3000m 2.4Mbps 1.3Mbps 1.1Mbps 5000m 0.79Mbps 0.44Mbps 0.35Mbps 6000m 0.25Mbps 0.15Mbps 0.1Mbps |
| PROTECTION | Transmission Channel Lightning 4KV 10/700us, common mode lightning : level 4 1KV 10/700us, differential mode lightning : Level 1Executive Standard : IEC61000-4-2 Product Electrostatic Protection 1a contact discharge Level 4 1b air discharge Level 4 Executive Standard : IEC61000-4-2 |
| RELIABILITY | MTBF >30000 hours |
| PHYSICAL | (including the terminal length) |
| CHARACTERISTIC | Material Aluminum Color BlackNet Weight 0.5KG / Pair Gross Weight 0.6KG / Pair |
| OPERATING | Working Temperature -30˚C ~ +60˚C |
| ENVIRONMENT | Storage Temperature 0˚C ~ +85˚C Humidity 0˚C ~ +95˚C |
